Descripción
The Cisco Meraki MS is the world’s first cloud-managed switch, bringing the benefits of the cloud to enterprise networks: simplified management, reduced complexity, network wide visibility and control, and lower cost for branch and campus deployments. Mission-critical features — like deep, Layer 7 application visibility, virtual stacking, QoS for business critical applications, 802.1X access control, and more — are present in both families.
The MS220 family provide layer 2 access switching, is ideal for deploying to branch locations, and supports an optional, rack-mountable remote PSU.
A Fresh Approach
Meraki switches are built from the ground up to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches.
Cisco Meraki switches are managed through an elegant, intuitive cloud interface, rather than a cryptic command line. To bring up a Meraki switch, just plug it in; there’s no need for complicated configuration files — or pre-staging.
In addition, Meraki’s centralized management system gives administrators deep visibility into the network and how it’s used. See which switches are near capacity across hundreds of sites. Find all configuration changes made by a certain person with instant search.
- 48 × 10/100/1000BASE-T Ethernet (RJ45) with auto-MDIX crossover
- 4 × SFP Gigabit Ethernet interfaces for uplink
- Auto negotiation and crossover detection
- 4 × SFP Gigabit Ethernet
- –
- 104 Gbps
- 100-240 VAC, 47-63 Hz
- 28/51 W max
- 19.08″ (w) x 14.17″ (l) x 1.75″ (h)(48.46 x 36 x 4.44 cm)
- 8.47 lb. (3.84 kg)
- 329,440
- 802.1p Quality of Service prioritization
- 802.1Q VLAN tagging and Q-in-Q VLAN stacking with 4096 addressable tags
- 802.1D Spanning Tree Protocol (RSTP, STP)
- 802.1ab Link Layer Discovery Protocol (LLDP)
- 802.3ad link aggregation with up to 8 ports per aggregate
- Broadcast storm control
- IGMP snooping for multicast filtering
- MAC forwarding table entries: 8,000
- Integrated two-factor authentication
- Role-based administration
- Corporate wide password policy enforcement
- IEEE 802.1X port-based security
- Non-blocking fabric
- 104 Gpbs non-blocking switching capacity
- 2.5 microsecond latency
- Managed via the cloud using the Meraki dashboard
- Integrated with Meraki wireless, routing, and firewall management
- No-touch remote deployment (no staging needed)
- Detailed historical per-port and per-client usage statistics
- DHCP and hostname fingerprinting
- SNMP v2c
- Seamless over-the-web firmware upgrades
- Email and text alerts
- Live remote packet capture
- Aggregated event logs with instant search
- Unified configuration and monitoring of all switches
- Virtually stack thousands of switch ports in a single logical stack for unified management, monitoring, and configuration
- Rack-mountable with included rack mount hardware
- Desktop-mountable with included feet
- Operating temperature: 32°F to 104°F (0°C to 40°C)
- Humidity: 5 to 95% non-condensing
- Silent operation for office environments
- Surface (wall/desk) mountable with integrated brackets
- CSA (US)
- IC (Canada)
- CE (Europe)
- C-Tick (Australia/New Zealand)
- RoHS
- Full lifetime hardware warranty with next-day advanced replacement included
